Smokebox - Unassembled Kit
Reverse Veiw
|
Parts Listing
SMOKEBOX SADDLE (1)
STEAM CONNECTION TUBES (4)
O RING (4)
SMOKEBOX (1)
SMOKEBOX DOOR (1)
SMOKEBOX BACK PLATE (1)
SMOKEBOX CROSSBAR (1)
SMOKEBOX DOOR HINGE (2)
BLOWER TUBE ASSEMBLY (1)
STRAIGHT ADAPTOR (1)
SANDBOX - LEFT (1)
SANDBOX - RIGHT (1)
HINGE BLOCK (2)
DOOR HINGE PIN (1)
OUTER HANDLE BOSS DETAIL (1)
OUTER HANDLE DETAIL (1)
INNER HANDLE BOSS DETAIL (1)
INNER HANDLE DETAIL (1)
SMOKEBOX DART (1)
DART BAR BRACKET (2)
5/16” PIPE TEE (2)
5/16” PIPE TEE (3)
PIPE ASSY - PUMP TO TEE (1)
PIPE ASSY - SUPPLY TO PUMP (1)
PIPE ASSY - TANK TO SUPPLY (2)
PIPE ASSY - SUPPLY TO TEE (1)
PIPE ASSY - TEE TO H/PUMP (1)
PIPE ASSY - TEE TO TEE (1)
PIPE ASSY - TEE TO CLACK (1)
OIL PIPE ASSEMBLY (1)
TURRET ELBOW (1)
|
